How to Install a Trailer Hitch on a Nissan Kicks
Adding a trailer hitch to a Nissan Kicks requires only a few tools, a CQT76518 trailer hitch, and a short amount of time to complete the installation. This trailer hitch and installation process will work for the Nissan Kicks model years 2018 - 2024.
Follow these basic steps to begin hauling trailers and other kinds of hitch-mounted accessories for your Nissan Kicks today.
Tools needed:
- Safety Glasses
- Power Drill
- Impact Driver
- Step Bit
- Tin Snips
- Exhaust Strap
- Exhaust Pliers
- Torque Wrench
- 5 Inch Extension
- 13mm, 12mm, and 15/16 Inch Sockets
2018-2024 Nissan Kicks Hitch Installation Steps
1. Lower the Exhaust
To begin our hitch installation process we will need to prep the underbody of the vehicle for the addition of the hitch. To start, we will need to lower the vehicle’s exhaust. To lower the exhaust we will be using our exhaust pliers and support strap.
2. Remove and Trim Heat Shield
Next, we will need to trim the vehicle’s heat shield. To do this we will be using our 15/16 inch sockets to remove each of its fasteners. Once the heat shield is removed we can make the necessary trims with our tin snips.
3. Lower Carbon Canister
Our next step will be to lower the carbon canister located on the driver’s side of the vehicle. For our vehicle, the carbon canister had a 13mm and 12mm bolt that needed to be removed.
4. Enlarge Acces Points
Following this we will need to enlarge the access found on the vehicle’s frame using our power drill and step bit.
5. Install Hardware
With the underbody of the vehicle now prepared we can begin installing the provided hardware. We will be using the fish wire technique to feed the hardware into each access hole.
6. Re-Install Heat Shield
Next, we can go ahead and re-install the heat shield with the fasteners we previously removed.
7. Raise Hitch Into Position
We can now raise our hitch into its proper position on the vehicle’s frame.
8. Install Remaining Hardware
With the hitch in place, we can now install the remaining hardware. We will be installing a washer and nut to each of the bolts that we previously installed.
9. Tighten and Torque Hitch
To properly secure the hitch to the vehicle’s frame, we will now tighten and torque the hardware according to the manufacturer’s specifications.
10. Re-install the Carbon Canister and Exhaust
To complete our hitch installation process, we will re-install the carbon canister and exhaust from our previous steps.
You should now have your trailer hitch installed on your Nissan Kicks.
How Much Does it Cost to Add a Hitch for a 2018-2024 Nissan Kicks?
The price range of a hitch for a Nissan Kicks ranges from $200 to $240. U-Haul carries several different classes of hitches and offers different sizes to accommodate both 1¼ to 2-inch receivers. U-Haul offers both installation services at a local U-Haul Moving Center® and will ship your hitch to your home.
How Much Does a Hitch for a 2018-2024 Nissan Kicks Cost?
Installation costs are normally $100 to $200 but you should check with your local U-Haul Moving Center® as prices can differ based on location, the hitch model you are installing, and your vehicle. All U-Haul Moving Centers can install a hitch to your vehicle and with over 1,500 U-Haul centers throughout the country, you can have your hitch installed and be back on the road in no time.
All trailer hitches sold and installed at a U-Haul Moving Center® come with the option of a lifetime warranty plan guaranteed to replace your hitch with no limitation for any damage, including collision, corrosion, accidental overload, jackknifing, and vehicle theft.
How Long Does it Take to Install a Hitch on a 2018-2024 Nissan Kicks?
Installation takes anywhere from 1 to 2 ½ hours depending on the hitch being installed and your vehicle. We recommend making an online appointment from our website to accommodate your busy schedule. In addition, U-Haul service centers offer an extensive line of towing accessories (Ball mount, Hitch ball, Pin, and Clip, Wiring) to help you safely tow your boat, camper, or trailer.
Do You Need a Wiring Kit for a 2018-2024 Nissan Kicks?
If you are planning to tow a trailer or camper with brake lights, running lights, and turn signal, you will want a wiring kit to power the lights on your trailer. The most common lighting harness comes in a 4 pin and 7 pin connector. The 4- way connector has basic lighting functions (running lights, brake lights, turn signal) while the 7-way connector adds a 12-volt circuit, circuit for electric trailer brakes, and reverse lights. U-Haul offers both 4-way and 7-way connectors. Find out which option is best for your Nissan Kicks.
