How to Install a Trailer Hitch on a Nissan Pathfinder
Adding a trailer hitch to a Nissan Pathfinder requires only a few tools, a Draw-Tite 13364 trailer hitch, and a short amount of time to complete the installation. This trailer hitch and installation process will work for the Nissan Pathfinder model year 2022.
Follow these basic steps to begin hauling trailers and other kinds of hitch-mounted accessories for your Nissan Pathfinder today.
Tools Needed:
- Safety Glasses
- Exhaust Removal Tool
- Exhaust Strap
- Power Drill with 3/16 Drill Bit
- Torque Wrench with 19mm Socket
- Trim Panel Removal Tool
- Soapy Water
Nissan Pathfinder Hitch Installation Steps
1. Remove Spare Tire
Our first step in this hitch installation process will be to remove the vehicle’s spare tire. To access the spare tire we will need to remove a bolt found underneath the floor panel.
2. Lower Exhaust
With the spare tire removed, we can now lower the vehicle’s exhaust as well. To start we will be applying a support strap to ensure the exhaust doesn’t hang. Now using our exhaust pliers we will remove the two rear-most exhaust hangers.
3. Trim Rear Fascia Panel
A trim is required on the vehicle’s rear fascia. We will be using an air saw to make this cut, however, any proper cutting tool should suffice.
4. Raise Hitch into Position
With the underbody of the vehicle now prepared for the addition of the hitch, we can now raise it into position.
5. Install Provided Hardware
To secure the hitch to the vehicle’s frame we will now install the provided hardware. Three bolts with conical washers will need to be installed on each side of the vehicle.
6. Tighten and Torque Hardware
Now with our hardware installed, we will tighten and torque the hitch according to the manufacturer’s specifications using a 19mm socket.
7. Re-Install Exhaust and Spare Tire
At this point, all you need to do to complete your hitch installation process is to re-install the vehicle’s exhaust and spare tire.
You should now have your trailer hitch installed on your Nissan Pathfinder.
How Much Does It Cost to Add a Hitch for a Nissan Pathfinder?
The price range of a hitch for a Nissan Pathfinder ranges from $270 to $280. U-Haul carries several different classes of hitches and offers different sizes to accommodate both 1¼ to 2-inch receivers. U-Haul offers both installation services at a local U-Haul Moving Center® and will ship your hitch to your home.
How Much Does a Hitch for a Nissan Pathfinder Cost?
Installation costs are normally $100 to $200 but you should check with your local U-Haul Moving Center® as prices can differ based on location, the hitch model you are installing, and your vehicle. All U-Haul Moving Centers can install a hitch to your vehicle and with over 1,500 U-Haul centers throughout the country, you can have your hitch installed and be back on the road in no time.
All trailer hitches sold and installed at a U-Haul Moving Center® come with the option of a lifetime warranty plan guaranteed to replace your hitch with no limitation for any damage, including collision, corrosion, accidental overload, jackknifing, and vehicle theft.
Nissan Pathfinder Hitch Prices
How Long Does It Take to Install a Hitch on a Nissan Pathfinder?
Installation takes anywhere from 1 to 2 ½ hours depending on the hitch being installed and your vehicle. We recommend making an online appointment from our website to accommodate your busy schedule. In addition, U-Haul service centers offer an extensive line of towing accessories (Ball mount, Hitch ball, Pin, and Clip, Wiring) to help you safely tow your boat, camper, or trailer.
Do You Need a Wiring Kit for a Nissan Pathfinder?
If you are planning to tow a trailer or camper with brake lights, running lights, and turn signal, you will want a wiring kit to power the lights on your trailer. The most common lighting harness comes in a 4 pin and 7 pin connector. The 4- way connector has basic lighting functions (running lights, brake lights, turn signal) while the 7-way connector adds a 12-volt circuit, circuit for electric trailer brakes, and reverse lights. U-Haul offers both 4-way and 7-way connectors. Find out which option is best for your Nissan Pathfinder.
